Description

Brass Differential Pressure Control Valve DPCV Valve

DPCV Valve Specifications:

DPCV Valve Techical Data:

Max operating pressure 16 bar

Max differential pressure over the body 2 bar

Min operating temperature -20⁰C

Max operating temperature up to DN32 130⁰C

Max operating temperature from DN40 110⁰C

DP Range 4202 4x 5 – 30 kPa

DP Range 4202 6x 25 – 60 kPa

DP Range 4202 7x 45 – 80 kPa

What is the Application and Purpose of Differential Pressure Control Valve (DPCV) :

The differential pressure controller is a straight-version linear controller and works without auxiliary power. The nominal differential pressure can be continuously adjusted from 50 to 300 mbar and 250 to 600 mbar, respectively. The value for the setting can be read from the diagram. The nominal set point is factory preset to a minimum. If necessary, the nominal set point can be adjusted using the pre-setting key (1 4002 01). A capillary (1000 mm) is included and should be connected to the circuit regulating valve in the flow.

Important note: The capillary must be connected when you make pressure tests and any isolating valves in the capillary must be open. During flushing, capillary isolating valves should be shut to prevent the valve from attempting to regulate the flow. To prevent damage of the body and the diaphragm a maximum differential pressure of 2 bar between supply and return is allowed at all times

Recommendation: Balancing Valve that Works with the Differential Pressure Valve

FBV4063 1/2- 2” BSP/NPT Solid Hot and Cold Water Brass Balancing Valve

Specifications

Materials Body: dezincification-resistant brass Membranes and O-rings: EPDM Water purity in accordance with the ÖNORM H 5195 and VDI 2035 standards Ethylene and propylene glycol can be mixed to a ratio of 25 – 50 vol. [%] EPDM gaskets can be affected by Mineral oils lubricants and thus lead to failure of the EPDM seals. Please refer to manufacturers documentation when using ethylene glycol products for frost and corrosion protection Installation The valve is fitted in the return flow in any orientation. The arrow on the valve body should align with the direction of flow. It is recommended that an isolation valve is fitted both upstream and downstream of the differential pressure controller

Approvals

Complies with Lead Free Plumbing Laws, NSF/ ANSI 61, UPC/ CE, ISO 9001

For approval information, please refer to the products specification sheet. For any other information on product certification and documentation information, please contact Fanovo.
